Specifications
General Product Information
| Weight | 1.70 kg |
| Power Supply Phase | 1-Ph |
| Supply Voltage | 1Ph 90-264V 50/60Hz |
| Dimension Length | 0.247 m |
| IP Rating | IP20 |
| Supply Frequency | 50 Hz
60 Hz |
| Dimension Height | 0.129 m |
| Dimension Width | 0.106 m |
| Connection Power | IEC EN60320 C14 – Male (for C13 plug on mains cable) |
| Measurement Channels | 1 Turbomolecular Pump |
| Available Units of Measurements | mbar |
Environmental Conditions
| Temperature Ambient Operation Max | 313.15 K |
| Temperature Ambient Operation Min. | 273.15 K |
| Temperature Ambient Storage Min. | 243.15 K |
| Temperature Ambient Storage Max. | 343.15 K |
Operation Conditions – Limitations
| Altitude Max. | 3000.00 m |
Connectivity – Communication Interface
| Communication Interfaces Customer | RS232 (serial)
RS485 (serial) |
| Connection electrical comms interface connector | DSUB 15-PIN – Female |
Performance Data
| Pressure Displayed Max. | 2.000 × 10⁵ Pa |
